Laser Line Mirrors are used for beam-steering in demanding laser applications. Laser Line Mirrors are Optical Mirrors that have been designed for specific laser types or wavelengths.
product origin:
Chinashipping port:
Fuzhou Chinalead time:
4 working weekspayment:
T/T Payment, Western Union1. What UNI Optics can offer for you?
The typical Specifications of Laser Mirror we can do are as follows:
Specifications:
Substrate Materials: N-BK7, Fused silica, Pyrex；
Dimensional tolerance: +/-0.1mm
Surface quality: 20-10
Parallelism: 1’
Flatness: λ/8 per 25mm@633nm
Bevel: Protective
One surface: Laser grade Polished and HR coating
The other surface: Fine ground
Angle of incident: 0° or 45°
2. What are the key features of Laser Mirror?
UNI Optics can produce the laser mirror with the following features:
Specified wavelength applications
High precision
High reflectivity
High damage threshold
3. Which wavelength can UNI Optics provide?
UNI Optics can offer the Laser Mirror with 355nm, 532nm, 1064nm, 1047nm, 1053n. Others can be available according to customers’ requirements.
| Part No. | Material | Wavelength(nm) | Incidence Angle | Φ(mm) | T(mm) |
| UMLM064001 | BK7 | 1064 | 45° | 25.4 | 6.35 |
| UMLM064002 | BK7 | 1064 | 45° | 25.4 | 6 |
| UMLM064003 | BK7 | 1064 | 45° | 50.8 | 6.35 |
| UMLM532003 | Fused silica | 532 | 0° | 25.4 | 6.35 |
| UMLM532004 | BK7 | 532 | 0° | 25.4 | 6.35 |
| UMLM532005 | Fused silica | 532 | 45° | 25.4 | 6.35 |
| UMLM532006 | BK7 | 532 | 45° | 25.4 | 6.35 |
| UMLM355001 | Fused silica | 355 | 0° | 25.4 | 6.35 |
| UMLM355002 | Fused silica | 355 | 45° | 25.4 | 6.35 |
High Reflective Broadband Dichroic Mirrors
N-BK7 metallic coated mirror
1、What Metallic Coated types can Uni-Optics supply?
Uni-Optics mainly offers four coating types, including:
1) UV Enhanced Aluminum : Ravg > 85% from 250nm to 400nm
2) Protected Aluminum: Ravg > 87% from 400nm to 800nm
3) Protected Silver: Ravg > 95% from 400nm to 20um
4) Protected Gold: Ravg > 98% from 650nm to 16um
2、What are the features of Metallic coated mirror?
Metallic coated mirror have many key features below:
Wide spectral range
Not sensitive to the incidence angle and polarization state
Low cost
Non-durable
Relatively low reflectance
Low laser damage threshold
3、What UNI Optics can do for you?
Common Specifications:
Substrate Materials: N-BK7, Fused silica, Pyrex；Float glass
Dimensional tolerance: +/-0.1mm
Surface quality: 60-40
Parallelism: 3’
Flatness: λ/4 per 25mm@633nm
Bevel: Protective
One surface: Polished and Metallic coating
The other surface: Fine ground
Note: Aluminum is the most widely used metal reflection film, from near UV to near IR, have high reflectivity, and with low cost. Silver has higher reflectivity in the visible and near infrared wavelength than the aluminum film, but the silver in the air will be rapid oxidation, color darkening, makes the film performance and firmness declined rapidly. Gold film has a good consistency with high reflectivity in the near, middle and far infrared range, can control the thermal radiation effectively, but it is relatively soft, easy bruising, and should be paid very close attention to clean, and the cost is very high.
High Precision Colored Glass Filters
UN-TFA1228C-10MP
|
Taurus Series Compact FA Lens(10MP) |
|||||
|
Model |
UN-TFA1228C-10MP |
||||
|
Focal length |
12mm |
|
|||
|
Aperture |
F2.8-16 |
||||
|
Image Format |
2/3"(11mm) |
||||
|
Mount |
C |
||||
|
Field Angle D x H x V (°) |
|
2/3″ |
1/2″ |
1/3" |
|
|
D |
49.2° |
36.9° |
28.1° |
||
|
H |
40.3° |
29.9° |
22.7° |
||
|
V |
30.8° |
22.7° |
17.1° |
||
|
Optical Distortion |
0.037% y=5.5mm |
-0.17% y=4.0mm |
-0.15% y=4.0mm |
||
|
M. O. D. |
0.15m~∞ |
||||
|
Dimension |
Φ29*41.5mm |
||||
|
Flange BFL |
17.526mm |
||||
|
Back Focal Length |
8.43mm |
||||
|
Operation |
Manual Iris |
||||
|
Manual Focus |
|||||
|
Design Wavelength |
420-1000nm |
||||
|
Filter Thread |
M27×P0.5 |
||||
 |
|||||
UN-TFA0921C
Product Features:
1. Compatible for 2/3'' Format Sensor
2. Ultra-compact Design
3. Ultra Low Distortion
4. High Relative Illumination
5. High Cost Performance
6. Supply with Focus and Iris locking screws.
Product information: Custom designs are available upon request.
VIS-NIR Coated Double-Concave (DCV) Lenses
N-BK7 and Fused Silica Wedge Prisms
UN-TFA3528C-10MP
|
Taurus Series Compact FA Lens(10MP) |
|||||
|
Model |
UN-TFA3528C-10MP |
||||
|
Focal length |
35mm |
|
|||
|
Aperture |
F2.8-16 |
||||
|
Image Format |
2.3″ |
||||
|
Mount |
C |
||||
|
Field Angle D x H x V (°) |
|
2/3″ |
1/2″ |
1/3" |
|
|
D |
18.39° |
13.4° |
10.1° |
||
|
H |
14.8° |
10.8° |
8.10° |
||
|
V |
11.1° |
8.10° |
6.10° |
||
|
Optical Distortion |
-0.172%y=5.5mm |
-0.077%y=4.5mm |
-0.045%y=4.0mm |
||
|
M. O. D. |
0.2m~∞ |
||||
|
Dimension |
Φ28*36.17mm |
||||
|
17.526mm |
|||||
|
Back Focal Length |
13.63mm |
||||
|
Operation |
Manual Iris |
||||
|
Manual Focus |
|||||
|
Design Wavelength |
420-1000nm |
||||
|
Filter Thread |
M27xP0.5 |
||||
 |
|||||
UN-TFA1620X-12MP
|
Taurus Series 4/3″Format FA Lens(12MP) |
|||||
|
Model |
UN-TFA1620X-12MP |
||||
|
Focal length |
16mm |
|
|||
|
Aperture |
F2.0-F22 |
||||
|
Image Format |
4/3″(23mm) |
||||
|
Mount |
C |
||||
|
Field Angle D x H x V (°) |
|
4/3″ |
1″ |
1/2" |
|
|
D |
73.0° |
54.2° |
28.3° |
||
|
H |
61.0° |
44.3° |
22.7° |
||
|
V |
47.3° |
33.6° |
17.1° |
||
|
Optical Distortion |
-1.93%@ y=11.5mm |
-1.82%@ y=8.0mm |
-0.55%@ y=4.0mm |
||
|
M. O. D. |
0.1m |
||||
|
Dimension |
Φ60.2*85.9mm |
||||
|
Back Focal Length |
21mm |
||||
|
Design Wavelength |
420~1000nm |
||||
|
Operation |
Manual Iris |
||||
|
Manual Focus |
|||||
|
Filter Thread |
M58.0×P0.75 |
||||
|
Weight |
339g |
||||
|
Work Temperature |
-20℃～+60℃ |
||||
|
|
|||||
Visible and NIR Plate Beamsplitters
UV Fused Silica Plano-Convex (PCX) Lenses
