UN-TFA0614C

Product Features:


1. Compatible for 2/3'' Format Sensor

2. Ultra-compact Design

3. Ultra Low Distortion

4. High Relative Illumination

5. High Cost Performance

6. Supply with Focus and Iris locking screws.


Product information: Custom designs are available upon request.

Download the datasheet of UN-TFA0614C


Inquiry now
  • description


Taurus Series Compact FA Lens(6MP)

Model

UN-TFA0614C

Focal length

6mm





Aperture

F1.4

Image Format

1/2

Mount

C



Field Angle

D x H x V (°)



2/3

1/2

1/3"

D

85.02°

67.38°

53.13°

H

72.51°

56.14°

43.60°

V

57.62°

47.60°

33.40°

Optical Distortion

<-1.1%

M. O. D.

0.2m

Dimension

Φ32.5*36.65mm

Flange BFL

17.526mm

Back Focal Length

9.177mm

Operation

Manual  Iris

Manual  Focus

Design Wavelength

400-900nm

Filter Thread

M30.5*0.5
