Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4· High relative illumination
· Lens for 2K, 4K, 8K line scan camera
· Excellent optical performance, uniform imaging of center and edge
Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4|
Aries Series Line Scan Lens(2K) |
||
|
Model |
UN-ALS502K01 |
|
|
Focal length |
50mm |
|
|
Fixed Aperture |
2.8 |
|
|
Image Format |
30 |
|
|
Mount |
M42 |
|
|
Field Angle |
32.3°*26°*19.7° |
|
|
Optical Distortion |
<-0.03% |
|
|
M. O. D. |
0.2m |
|
|
Dimension |
Φ45.2*29.42mm |
|
|
Flange BFL |
46.5mm |
|
|
Back Focal Length |
35.5mm |
|
|
Operation |
Manual Iris |
|
|
Manual Focus |
||
|
Filter Thread |
M43*0.75 |
|
 |
||
