Optical glass Plano Convex Circular Cylindrical Lenses

Plano-convex circular cylindrical lenses are useful for line imaging or uni-axial magnification in a wide range of applications. These lenses may be combined with other lenses to form complex imaging systems.
  • product origin:

    China
  • shipping port:

    Fuzhou China
  • lead time:

    4 working weeks
  • payment:

    T/T Payment, Western Union
Inquiry now
  • description

UNI Optics’s Plano Convex Circular Cylindrical Lens has a convex curvature in the vertical direction and has no curvature in the horizontal direction. They are edged as circular shapes so they can easily be combined with other elements in an optical system.



1、How to control the radius correctly?


Uni Optics use the precision templet for processing to make sure the final R value matched your drawings.



2、Can you provide the testing report?


Yes. We can offer the actual testing data including Radius, centration, dimensions, surface quality, coating curve, etc..



 Plano-Convex Circular Cylindrical Lenses  Plano-Convex Circular Cylindrical Lenses


Common specification

Material: Schott, CDGM, Ohya, Ohara, Corning, etc.

Diameter tolerance: +0/-0.05mm

Effective Focal Length Tolerance:±2%

Centering Tolerance:≤3 arc min

Surface Quality: 40-20 S/D

Surface flatness: N=5△N=0.5

Clear aperture:  > 90 % of surface dimensions

Coating: Optional ( Uncoated / Single layer MgF2 / Broadband AR )


Part NO. Material F(mm) Φ(mm) R(mm) Tc(mm) Te(mm) Fb(mm)
ULYRPX008005 BK7 8 5 4.13 2.84 2 6.14
ULYRPX092008 BK7 9.2 8 4.74 4.2 2 6.44
ULYRPX010008 BK7 10 8 5.17 3.9 2 7.43
ULYRPX125127 BK7 12.5 12.7 6.43 7.44 2 7.57
ULYRPX025127 BK 25 12.7 12.88 3.67 2 22.58
ULYRPX050127 BK7 50 12.7 25.75 2.8 2 48.17
ULYRPX075254 BK7 75 25.4 38.64 4.15 2 72.28
ULYRPX100254 BK7 100 25.4 51.52 4.59 2 96.99
ULYRPX150254 BK7 150 25.4 77.27 4.05 2 147.34
