SWIR Lens UN-GSWIR0618C

For Vision-Guided Positioning Systems, Semiconductor Defect Inspection, Agricultural Remote Sensing Imaging, Hyperspectral Camera, etc.

· Developed for 1" image format
· Wavelength: 900-1700nm
· Large Aperture, up to F1.4
· Compact and lightweight design

For Semiconductor Wafer Inspection, Wildfire Detection & Ember Monitoring, etc.

· Developed for 1" image format
· Wavelength: 900-1700nm
· Large Aperture, up to F1.4
· Compact and lightweight design

For Semiconductor Wafer Inspection, Biomedical Imaging, Logistics Package Sorting, Wildfire Detection & Ember Monitoring, etc.

· Developed for 1.1" image format
· Wavelength: 800-1700nm
· Large Aperture, up to F2.0
· Compact and lightweight design

For Automated Optical Inspection (AOI), Food Sorting, Recycling Sorting, etc.

· Developed for 1" image format
· Wavelength: 900-1700nm
· Large Aperture, upto F1.4
· Compact and lightweight design

For Photovoltaic Inspection, Pill / Capsule Detection, Print Inspection, Hyperspectral Camera, etc.

· Developed for 1" image format
· Wavelength: 900-1700nm
· Large Aperture, up to F1.4
· Compact and lightweight design

1、What are laser windows?

Laser Protect Windows(Laser protective glass, protective filters or welding protective windows) are used to save for the high cost of laser optics.

2、What are laser windows used for?

These windows are normally used in applications like laser cutting, laser welding machine, they are used for avoiding the high-precision laser optics damage by material splashes.

3、The key features of UNI Optics' Laser Windows

High Transmission

High Damage Threshold

Low Scatter

Low Absorption

Excellent Film Density

Excellent Environmental Stability

Typical Specifications:

Dimension: 4mm-80mm, round or square

Material: BK7, Fused Silica, ZnSe...etc

Surface quality: 10/5

Surface flatness: Lambda/10@632.8nm

Parallelism: 30’’

Roughness: 3A

For High-Precision Machine Vision Applications: Consumer Electronics Dimensional Inspection, Surface Defect Detection, OCR & Code Reading, Robotic Guidance, Biomedical Imaging and so on.

· Developed for 1/1.8" image format
· Low distortion
· High relative illumination

· Focus and iris fixed with screw

Product information: Custom designs are available upon request.
