High Power Laser Line Windows

Inquiry now
  • description

1、What is laser windows?


Laser Protect Windows(Laser protective glass, protective filters or welding protective windows) are used to save for the high cost of laser optics.


2、What is laser windows used for?


These windows are normally used in applications laser cutting, laser welding machine, it used for avoid the high-precision laser optics damage by material splashes.


3、The key features of UNI Optics' Laser Windows


High Transmission

High Damage Threshold

Low Scatter

Low Absorption

Excellent Film Density

Excellent Environmental Stability


Laser Windows   Laser Windows

Typical Specifications:



Dimension: 4mm-80mm, round or square

Material: BK7, Fused Silica, ZnSe...etc

Surface quality: 10/5

Surface flatness: Lambda/10@632.8nm

Parallelism: 30’’

Roughness: 3A
