Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4· High relative illumination
· Lens for 2K, 4K, 8K line scan camera
· Excellent optical performance, uniform imaging of center and edge
UN-ALS354K
Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4
UN-ALS50TM42
Product Features:
1. Compatible for 30mm Large Format Sensor
2. Large Aperture with F2.4
3. High Relative Illumination
4. Compatible for 2K-4K line scan camera
5. Ultra-low Distortion, low vertical axis chromatic aberration
6. Vibration-resistant and high stability.
Product information: Custom designs are available upon request.
Download the Datasheet of UN-ALS50TM42
UN-ALS502K
Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4
UN-ALS502K01
Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4
UN-ALS50J01
Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4
UN-ALS508K01
Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4
UN-ALS858K
|
Aries Series Line Scan Lens(8K) |
||
|
Model |
UN-ALS858K |
|
|
Focal length |
85mm |
|
|
Aperture |
F2.8 |
|
|
Image Format |
38 |
|
|
Mount |
M42 |
|
|
Field Angle |
23.1°*16.8°*9.1° |
|
|
Optical Distortion |
<-0.15% |
|
|
M. O. D. |
0.6m |
|
|
Dimension |
Φ58.5*59.87mm |
|
|
Flange BFL |
46.5mm |
|
|
Back Focal Length |
23.93mm |
|
|
Operation |
Manual Iris |
|
|
Manual Focus |
||
|
Filter Thread |
M55*0.75 |
|
 |
||
UN-GSWIR1614C
|
Gemini Series SWIR Lens |
|||
|
Model |
UN-GSWIR1614C |
||
|
Focal length |
16mm |
|
|
|
Aperture |
F1.4 |
||
|
Image Format |
1″ |
||
|
Mount |
C |
||
|
Field Angle |
|
1″ |
|
|
D |
54° |
||
|
H |
43.8° |
||
|
V |
33.4° |
||
|
Optical Distortion |
<-0.6% |
||
|
M. O. D. |
0.3m |
||
|
Dimension |
Φ54*63.00mm |
||
|
Flange BFL |
17.526mm |
||
|
Back Focal Length |
13.72mm |
||
|
Resolution |
80lp/mm |
||
|
Operation |
Manual Iris |
||
|
Manual Focus |
|||
|
Design Wavelength |
900-1700nm |
||
|
Filter Thread |
M52x0.75 |
||
 |
|||
UN-TFA2518X-12MP
|
Taurus Series 4/3″ Format FA Lens(12MP) |
|||||
|
Model |
UN-TFA2518X-12MP |
||||
|
Focal length |
25mm |
|
|||
|
Aperture |
F2.0-F22 |
||||
|
Image Format |
4/3″(23mm) |
||||
|
Mount |
C |
||||
|
Field Angle D x H x V (°) |
|
4/3″ |
1″ |
1/2" |
|
|
D |
49.8° |
35.8° |
18.3° |
||
|
H |
40.6° |
28.9° |
14.6° |
||
|
V |
31.1° |
21.8° |
11.1° |
||
|
Optical Distortion |
-0.64%@ y=11.5mm |
-0.48%@ y=8.0mm |
-0.15%@ y=4.0mm |
||
|
M. O. D. |
0.15m |
||||
|
Dimension |
Φ47.3*82.7mm |
||||
|
Back Focal Length |
22mm |
||||
|
Design Wavelength |
420~1000nm |
||||
|
Operation |
Manual Iris |
||||
|
Manual Focus |
|||||
|
Filter Thread |
M46.0×P0.75 |
||||
|
Weight |
248g |
||||
|
Work Temperature |
-20℃～+60℃ |
||||
|
|
|||||
