· Developed for 1" image format
· Wavelength: 900-1700nm
· Large Aperture, upto F1.4
· Compact and lightweight design
UN-GSWIR0814CL
UN-GSWIR1614C
|
Gemini Series SWIR Lens |
|||
|
Model |
UN-GSWIR1614C |
||
|
Focal length |
16mm |
|
|
|
Aperture |
F1.4 |
||
|
Image Format |
1″ |
||
|
Mount |
C |
||
|
Field Angle |
|
1″ |
|
|
D |
54° |
||
|
H |
43.8° |
||
|
V |
33.4° |
||
|
Optical Distortion |
<-0.6% |
||
|
M. O. D. |
0.3m |
||
|
Dimension |
Φ54*63.00mm |
||
|
Flange BFL |
17.526mm |
||
|
Back Focal Length |
13.72mm |
||
|
Resolution |
80lp/mm |
||
|
Operation |
Manual Iris |
||
|
Manual Focus |
|||
|
Design Wavelength |
900-1700nm |
||
|
Filter Thread |
M52x0.75 |
||
 |
|||
UN-GSWIR2514C
|
Gemini Series SWIR Lens |
|||
|
Model |
UN-GSWIR2514C |
||
|
Focal length |
25mm |
|
|
|
Aperture |
F1.4 |
||
|
Image Format |
1″ |
||
|
Mount |
C |
||
|
Field Angle |
|
1″ |
|
|
D |
61.93° |
||
|
H |
52.21° |
||
|
V |
40.1° |
||
|
Optical Distortion |
<-0.96% |
||
|
M. O. D. |
0.3m |
||
|
Dimension |
Φ36.5*54.91mm |
||
|
Flange BFL |
17.526mm |
||
|
Back Focal Length |
11.51mm |
||
|
Resolution |
80lp/mm |
||
|
Operation |
Manual Iris |
||
|
Manual Focus |
|||
|
Design Wavelength |
900-1700nm |
||
|
Filter Thread |
M34*0.5 |
||
 |
|||
