UN-ST5528-5MP

Aries Series Line Scan Lens(8K)

Model

UN-ALS858K

Focal length

85mm

Aperture

F2.8

Image Format

38

Mount

M42

Field Angle

D x H x V (°)

23.1°*16.8°*9.1°

Optical Distortion

<-0.15%

M. O. D.

0.6m

Dimension

Φ58.5*59.87mm

Flange BFL

46.5mm

Back Focal Length

23.93mm

Operation

Manual  Iris

Manual  Focus

Filter Thread

M55*0.75

Taurus Series 4/3″Format FA Lens(12MP)

Model

UN-TFA1620X-12MP

Focal length

16mm

Aperture

F2.0-F22

Image Format

4/3″(23mm)

Mount

C

Field Angle

D x H x V (°)

4/3″

1″

1/2"

D

73.0°

54.2°

28.3°

H

61.0°

44.3°

22.7°

V

47.3°

33.6°

17.1°

Optical Distortion

-1.93%@

y=11.5mm

-1.82%@

y=8.0mm

-0.55%@

y=4.0mm

M. O. D.

0.1m

Dimension

Φ60.2*85.9mm

Back Focal Length

21mm

Design Wavelength

420~1000nm

Operation

Manual  Iris

Manual  Focus

Filter Thread

M58.0×P0.75

Weight

339g

Work Temperature

-20℃～+60℃

Taurus Series Compact FA Lens(10MP)

Model

UN-TFA1628C-10MP

Focal length

16mm

Aperture

F2.8-16

Image Format

2/3″

Mount

C

Field Angle

D x H x V (°)

2/3″

1/2″

1/3"

D

37.9

28.1°

21.2°

H

30.7°

22.6°

17.0°

V

23.3°

17.1°

12.8°

Optical Distortion

0.29%@y=5.5mm

0.15%@y=4.0mm

0.08%@y=3.0mm

M. O. D.

0.15m~∞

Dimension

Φ29*41.50mm

Flange BFL

17.526mm

Back Focal Length

8.63mm

Operation

Manual Iris

Manual Focus

Design Wavelength

420-1000nm

Filter Thread

M27xP0.5
