UN-TFA2518C-10MP

Taurus Series Compact FA Lens(10MP)

Model

UN-TFA0828C-10MP

Focal length

8mm

Aperture

F2.8-16

Image Format

2/3"(11mm)

Mount

C

Field Angle

D x H x V (°)

2/3″

1/2″

1/3"

D

69.7°

50.7°

38.0°

H

58.5°

 42.5°

31.9°

V

45.5°

33.1°

24.8°

Optical Distortion

-0.81%@

y=5.5mm

-1.13%@ y=4.0mm

-0.93%@ y=3.0mm

M. O. D.

0.15m~∞

Dimension

Φ35*39.8mm

Flange BFL

17.526mm

Back Focal Length

10.7mm

Operation

Manual Iris

Manual Focus

Design Wavelength

420-1000nm

Filter Thread

M32.7×P0.5

Taurus Series Compact FA Lens(10MP)

Model

UN-TFA1228C-10MP

Focal length

12mm

Aperture

F2.8-16

Image Format

2/3"(11mm)

Mount

C

Field Angle

D x H x V (°)

2/3″

1/2″

1/3"

D

49.2°

36.9°

28.1°

H

40.3°

29.9°

22.7°

V

30.8°

22.7°

17.1°

Optical Distortion

0.037%

y=5.5mm

-0.17% y=4.0mm

-0.15% y=4.0mm

M. O. D.

0.15m~∞

Dimension

Φ29*41.5mm

Flange BFL

17.526mm

Back Focal Length

8.43mm

Operation

Manual Iris

Manual Focus

Design Wavelength

420-1000nm

Filter Thread

M27×P0.5

Taurus Series Compact FA Lens(10MP)

Model

UN-TFA1628C-10MP

Focal length

16mm

Aperture

F2.8-16

Image Format

2/3″

Mount

C

Field Angle

D x H x V (°)

2/3″

1/2″

1/3"

D

37.9

28.1°

21.2°

H

30.7°

22.6°

17.0°

V

23.3°

17.1°

12.8°

Optical Distortion

0.29%@y=5.5mm

0.15%@y=4.0mm

0.08%@y=3.0mm

M. O. D.

0.15m~∞

Dimension

Φ29*41.50mm

Flange BFL

17.526mm

Back Focal Length

8.63mm

Operation

Manual Iris

Manual Focus

Design Wavelength

420-1000nm

Filter Thread

M27xP0.5

Taurus Series Compact FA Lens(10MP)

Model

UN-TFA3528C-10MP

Focal length

35mm

Aperture

F2.8-16

Image Format

2.3″

Mount

C

Field Angle

D x H x V (°)

2/3″

1/2″

1/3"

D

18.39°

13.4°

10.1°

H

14.8°

10.8°

8.10°

V

11.1°

8.10°

6.10°

Optical Distortion

-0.172%y=5.5mm

-0.077%y=4.5mm

-0.045%y=4.0mm

M. O. D.

0.2m~∞

Dimension

Φ28*36.17mm

Flange BFL

17.526mm

Back Focal Length

13.63mm

Operation

Manual Iris

Manual Focus

Design Wavelength

420-1000nm

Filter Thread

M27xP0.5

Taurus Series Compact FA Lens(10MP)

Model

UN-TFA5028C-10MP

Focal length

50mm

Aperture

F2.8-16

Image Format

2.3″

Mount

C

Field Angle

D x H x V (°)

2/3″

1/2″

1/3"

D

12.27°

9.16°

6.89°

H

10.08°

7.34°

5.51°

V

7.57°

5.51°

4.13°

Optical Distortion

0.094% y=5.5mm

0.055% y=4.0mm

0.025% y=3.0mm

M. O. D.

0.3m~∞

Dimension

Φ29*55.30mm

Flange BFL

17.526mm

Back Focal Length

14.24mm

Operation

Manual Iris

Manual Focus

Design Wavelength

420-1000nm

Filter Thread

M27xP0.5

Taurus Series Compact FA Lens(10MP)

Model

UN-TFA1228C-10MP

Focal length

12mm

Aperture

F2.8-16

Image Format

2/3"(11mm)

Mount

C

Field Angle

D x H x V (°)

2/3″

1/2″

1/3"

D

49.2°

36.9°

28.1°

H

40.3°

29.9°

22.7°

V

30.8°

22.7°

17.1°

Optical Distortion

0.037%

y=5.5mm

-0.17% y=4.0mm

-0.15% y=4.0mm

M. O. D.

0.15m~∞

Dimension

Φ29*41.5mm

Flange BFL

17.526mm

Back Focal Length

8.43mm

Operation

Manual Iris

Manual Focus

Design Wavelength

420-1000nm

Filter Thread

M27×P0.5
