BBAR Coated Hypotenuse Right Angle Prisms

Right Angle Prisms are typically used to bend image paths or for redirecting light at 90°. Right Angle Prisms are Prisms designed with a 90° angle. Right Angle Prisms produce inverted or reverted left handed images, depending on the orientation of the prism. Using two Right Angle Prisms together is ideal for image or beam displacement applications. These prisms are also known as image reflection or reflecting prisms.
  • product origin:

    China
  • shipping port:

    Fuzhou China
  • lead time:

    4 working weeks
  • payment:

    T/T Payment, Western Union
Inquiry now
  • description

1.What is right angle prism used for?



Right Angle Prisms are typically used to bend image paths or for redirecting light. It is used to deviate light through 90 degree, and it also can be used to deflect light through 180 degree by total internal reflection.



2.What kinds of materials can UNI Optics use to make right angle prism?



N-BK7 glass , UV Fused silica, other optical glass



3. What is UNI Optics standard manufacturing capability and top limit for right angle prism?


Specification

Standard capability

Top limit

Dimension Tolerance

+0/-0.2mm

+0/-0.05mm

Clear Aperture

>80%

>85%

Angle Tolerance

+/-3’

+/-10’’

Flatness

λ/4@632.8nm

λ/8@632.8nm

Surface quality

60-40

10-5


4. What is the typical size?


  AxBxC(mm)

     AxBxC(mm)

          AxBxC(mm)

   1.0x1.0x1.0

   12.7x12.7x12.7

   38.1x38.1x38.1

   2.0x2.0x2.0

   15.0x15.0x15.0

   40.0x40.0x40.0

   3.0x3.0x3.0

   18.0x18.0x18.0

   50.0x50.0x50.0

   5.0x5.0x5.0

   20.0x20.0x20.0

   50.8x50.8x50.8

   8.0x8.0x8.0

   25.4x25.4x25.4

   60.0x60.0x60.0

   10.0x10.0x10.0

   30.0x30.0x30.0

   70.0x70.0x70.0


Other sizes and shapes are available.
