Optical Glass Plano-Concave Lenses

Plano Concave Lenses are ideal for beam expansion, light projection, or for expanding an optical system's focal length. Plano Concave Lenses, which have one concave surface, are Optical Lenses with negative focal lengths. PCV Lenses should be shaped with the plano, or flat, surface towards the desired focal plane. PCV Lenses are ideal for use in a range of applications or industries. Uni-Optics offers PCV lenses with a variety of coating options.
  • product origin:

  • shipping port:

    Fuzhou China
  • lead time:

    4 working weeks
  • payment:

    T/T Payment, Western Union
Inquiry now
  • description

1.What are plano-concave lenses used for?

 Plano concave lenses, which have one concave surface, are optical lenses with negative focal lengths, they are ideal for beam expansion, light projection, or for expanding an optical system's focal length. Uni-Optics offers PCV lenses with a variety of coating options, and they are ideal for use in a range of applications or industries.

2.What kinds of materials can UNI Optics use to make plano-concave lenses?


CDGM optical glasses, SCHOTT, OHARA, Fused Silica, Sapphire, Germanium, Silicon, calcium fluoride (CaF2), Zinc Selenide (ZnSe), and other infrared materials.


3.What is UNI Optics manufacturing capability about plano-concave lenses?



Plano concave lenses

Material:    Optical glass&Fused silica

Design wavelength:    546.1nm
Diameter tolerance:    +0/-0.05mm
Focal tolerance:    +/-2%
surface quality :    40-20 S/D
Centration:    1 arcmin
Surface flatness:     N=3 △N=0.5
Clear aperture:    90%
Bevel:     Protective
Coating:  Optional
Single layer MgF2
Multiple layers BBAR coating
Designed for 0° Angle of Incidence

Part No. Material F(mm) Φ(mm) R(mm) Tc(mm) Te(mm) Fb(mm)
UPLV008006 BK7 -8.0 6.0 4.15 2.0 3.30 -9.30
UPLV020006 BK7 -20.0 6.0 -10.37 2.0 2.44 -21.30
UPLV030006 BK7 -30.0 6.0 -15.56 2.0 2.29 -31.32
UPLV020010 BK7 -20.0 10.0 -10.37 2.0 3.20 -21.30
UPLV030127 BK7 -30.0 12.7 -15.56 2.0 3.40 -31.31
UPLV040127 BK7 -40.0 12.7 -20.75 2.0 3.00 -41.32
UPLV050127 BK7 -50.0 12.7 -25.94 2.0 2.79 -51.33
UPLV075127 BK7 -75.0 12.7 -38.90 2.0 2.52 -76.31
UPLV100127 BK7 -100.0 12.7 -5, 1.88 2.0 2.39 -101.33
UPLV075015 BK7 -75.0 15.0 -38.87 2.0 2.70 -76.30
UPLV050018 BK7 -50.0 18.0 -25.94 2.0 3.61 -51.33
UPLV075018 BK7 -75.0 18.0 -38.90 2.0 3.05 -76.30
UPLV050254 BK7 -50.0 25.4 -25.94 2.0 5.32 -51.33
UPLV075254 BK7 -75.0 25.4 -38.90 2.0 4.13 -76.31
UPLV100254 BK7 -100.0 25.4 -51.88 2.0 3.58 -101.33
UPLV150254 BK7 -150.0 25.4 -77.80 2.0 3.04 -151.30
UPLV200254 BK7 -200.0 25.4 -103.75 2.0 2.78 -201.33
UPLV250254 BK7 -250.0 25.4 -129.72 2.0 2.62 -251.39
UPLV200030 BK7 -200.0 30.0 -103.75 2.0 3.09 -201.34
UPLV100038 BK7 -100.0 38.0 -51.88 2.0 5.60 -101.34
UPLV200038 BK7 -200.0 38.0 -103.75 2.0 3.76 -201.34
UPLV300038 BK7 -300.0 38.0 -155.60 2.0 3.16 -301.30
UPLV100508 BK7 -100.0 50.8 -51.88 2.0 8.64 -101.34
UPLV200508 BK7 -200.0 50.8 -103.75 2.0 5.16 -201.34
UPLV300508 BK7 -300.0 50.8 -155.60 2.0 4.00 -301.30
UPLV500508 BK7 -500.0 50.8 -259.40 2.0 3.25 -501.40
JPLV015127 JGS1 -15.0 12.7 6.90 2.0 6.20 -16.40
JPLV020127 JGS1 -20.0 12.7 9.20 2.0 4.50 -21.40
JPLV025127 JGS1 -25.0 12.7 11.50 2.0 3.90 -26.40
JPLV030127 JGS1 -30.0 12.7 13.80 2.0 3.50 -31.40
JPLV050254 JGS1 -50.0 25.4 23.00 2.0 5.80 -51.40
JPLV075254 JGS1 -75.0 25.4 34.51 2.0 4.40 -76.40
JPLV100254 JGS1 -100.0 25.4 46.01 2.0 3.80 -101.40
JPLV150254 JGS1 -150.0 25.4 69.01 2.0 3.20 -151.40
JPLV200038 JGS1 -200.0 38.0 92.02 3.0 5.00 -202.10
JPLV350038 JGS1 -350.0 38.0 161.03 3.0 4.10 -352.10
JPLV500038 JGS1 -500.0 38.0 230.04 3.0 3.80 -502.10
CPLV100254 CaF2 -100.0 25.4 42.50 2.0 3.90 -101.40
CPLV200254 CaF2 -200.0 25.4 85.00 2.0 3.00 -201.40
CPLV500254 CaF2 -500.0 25.4 212.50 2.0 2.40 -501.40
