AR coated Colour glass window

Color glass change the spectral properties of optical radiation. They therefore allow scientific experiments and industrial applications where that change is necessary. You can combine color glass filters together to change the band pass or to increase the attenuation.
  • product origin:

    China
  • shipping port:

    Fuzhou China
  • lead time:

    4 working weeks
  • payment:

    T/T Payment, Western Union
Inquiry now
  • description

Color glass change the spectral properties of optical radiation. They therefore allow scientific experiments and industrial applications where that change is necessary. You can combine color glass filters together to change the band pass or to  increase the attenuation.


color glass windows  color glass windows


Specifications:


Material:

Color Glass Type(Cut-off Glass, Absorption-Selective Glass, Neutral Glass)

Dimension Tolerance:

 +0.0, -0.1mm

Thickness Tolerance:

 ± 0.1mm

Surface quality:

 60/40(Standard), 10/5(High Precision)

Clear Aperture:

 >85%

Flatness:

 λ(Standard), λ/10(High Precision) per 25mm@633nm

Parallelism:

 1' (Standard),  10" (High Precision)

Bevel:

 <0.25mm X 45°

Coating:

 Upon requirement
